Main features
Large steel hopper, capable of receiving even the bulkiest branches and twigs, without prior reworking. Thus, it also features a large capacity that allows entering large volumes of material at once.
Equipped with flanged coupling for walking tractors with PTO shaft for drive.
PTO shaft FEATURES:
- 10 teeth (or 10 splines)
- Teeth external diameter: 18 mm
- Teeth internal diameter: 15 mm
Flange hole spacing: 10 cm
Configuration adaptable to the following two-wheel models:
- Grillo: 125 - 126
- Grillo: G85 - G107
- BCS: 601 - 602 - 603 - 604 - 612
- BCS: 715 - 725 - 735 - 737
- Ferrari: 305 - 306 - 307
- Ferrari: 90SLB - 792 - 794
- Ginko MGM 710
Not directly applicable to other two-wheel tractors on the market that are not listed above.
In this case, you will have to provide yourself with an adapter (which you may have to request personally from the manufacturer of your walking tractor) and which we are unable to supply.
Optimal cutting mechanism, highly effective and productive, which distinguishes this product from all the competition. It consists of:
- no. 2 + 1 large, thick cutting blades (there are 3 in total), mounted on a rotating steel disc at the end of the hopper.
They carry out pre-processing, cutting the material in the hopper into coarser fragments.
- no. 6 high-speed rotating hardened steel hammers (they are located immediately behind the 3 above-mentioned blades) They perform a centrifugal operation, reducing the material into small fragments
Equipped with INTERMEDIATE BELT TRANSMISSION.
This gives the machine an uncommon solidity, protecting both the engine and the entire grinding mechanism from any kind of shock or kickback.
Triple the service life compared to the old system still used by many manufacturers with an internal combustion engine directly connected to the shredding chamber.
The discharge chute is equipped with a grid, which ensures that fragments are only ejected when finely ground by the hammers
Equipped with a large and robust grinding chamber. The shredding chamber also has a rounded shape. It guarantees excellent productivity, as well as the durability in time.
The machine body and frame are 100 % made of steel. There is no plastic on this product
It has a very good cutting diameter: Max 50 mm
Discharge chute provided with adjustable direction
Robust, large rubber wheels
Warning: Like all wood chippers and garden shredders, it is not suited for shredding grass, leaves, pine needles, etc. (it is intended to shred branches, but it can also grind leaves, needles and others)
Shredders intended use:
- The shredder must grind only green branches and not dried ones (which would limit its shredding capacity and lead to rapid deterioration of the blades);
- The branches must be preferably long, smooth and not knobby (otherwise the cutting diameter would be reduced);
- The branch cutting diameter indicated is the maximum, so it is advised not to shred larger branches. In this case it would be better to purchase a shredder with a larger branch cutting diameter;
- The cutting diameter can vary according to the amounts of wood (e.g: oak, olive, plum and peach are hardwoods and can reduce the cutting capacity of the wood chipper)
